Series 01 - Short Series drills feature a HSS-Co 8% uncoated construction ideal for general production machining, offering both good wear resistance and tool hardness. 2 Flutes allow for efficient cutting performance coupled with excellent chip control.
Features and Benefits
HSS-Co construction for excellent durability and tool hardness
2 flutes for efficient cutting performance and and chip control
Ideal for general production machining for reduced downtime and tool replacement
Weldon shank for greater tool stability
Typical Applications
Centre cutting
Milling
General production machining
Standards
Dimensions to DIN 327
Weldon shank to DIN 1835B
| Cutting Direction | Right Hand |
| Shank Diameter Tolerance | H6 |
| Shank Diameter | 20mm |
| Finish/Coating | Uncoated |
| Material | Cobalt High Speed Steel |
| Plunge Type | Centre Cutting |
| Cutter Diameter | 22mm |
| Cutter Diameter Tolerance | e8 |
| Shank Type | Weldon Flat |
| Series | 1 |
| Cutter Style | Square End |
| Overall Length | 88.0mm |
| Length Type | Short |
| Flute Type | Helical |
| Number of Flutes | 2 |
| Coolant Delivery | External |
| System of Measurement | Metric |
| Material Grade | M42 |
| End Mill Type | Slot Drill |
| Standards Met | DIN 327 | DIN 1835B |
| Milling Cutter Type | Slot Drill |
| Flute Length | 22mm |
