Series 01 - Short Series drills feature a HSS-Co 8% uncoated construction ideal for general production machining, offering both good wear resistance and tool hardness. 2 Flutes allow for efficient cutting performance coupled with excellent chip control.
Features and Benefits
HSS-Co construction for excellent durability and tool hardness
2 flutes for efficient cutting performance and and chip control
Ideal for general production machining for reduced downtime and tool replacement
Weldon shank for greater tool stability
Typical Applications
Centre cutting
Milling
General production machining
Standards
Dimensions to DIN 327
Weldon shank to DIN 1835B
| Series | 1 |
| End Mill Type | Slot Drill |
| Number of Flutes | 2 |
| Material | Cobalt High Speed Steel |
| Overall Length | 88.0mm |
| Cutter Style | Square End |
| Coolant Delivery | External |
| System of Measurement | Metric |
| Shank Type | Weldon Flat |
| Cutter Diameter Tolerance | e8 |
| Flute Length | 22mm |
| Flute Type | Helical |
| Material Grade | M42 |
| Shank Diameter Tolerance | H6 |
| Milling Cutter Type | Slot Drill |
| Standards Met | DIN 327 | DIN 1835B |
| Finish/Coating | Uncoated |
| Shank Diameter | 20mm |
| Cutting Direction | Right Hand |
| Length Type | Short |
| Plunge Type | Centre Cutting |
| Cutter Diameter | 20mm |
