Series 07 - Long Series
Dimensions to DIN 844 Centre cutting. Weldon shank to DIN 1835B. Cutting diameter to e8. Shank diameter to h6.
Uncoated (for general production machining)
TiCN Coated (extends cutter life and improves work material surface finish) TiALN Coated (dissipates and resists heat, reduces surface friction coupled with high surface hardness).
| Number of Flutes | 3 |
| Milling Cutter Type | Slot Drill |
| Shank Type | Weldon Flat |
| Cutter Diameter Tolerance | e8 |
| Flute Length | 75.00mm |
| Series | 07 |
| End Mill Type | Slot Drill |
| Material | Cobalt High Speed Steel |
| Flute Type | Helical |
| Shank Diameter | 20.00mm |
| Cutter Diameter | 20.00mm |
| Cutter Style | Square |
| Material Grade | M42 |
| Shank Diameter Tolerance | H6 |
| Cutting Direction | Right Hand |
| Length Type | Long |
| System of Measurement | Metric |
| Plunge Type | Centre Cutting |
| Standards Met | DIN 844 | DIN 1835B |
| Finish/Coating | Uncoated |
| Overall Length | 141.00mm |
| Coolant Delivery | External |
