Series 07 - Long Series
Dimensions to DIN 844 Centre cutting. Weldon shank to DIN 1835B. Cutting diameter to e8. Shank diameter to h6.
Uncoated (for general production machining)
TiCN Coated (extends cutter life and improves work material surface finish) TiALN Coated (dissipates and resists heat, reduces surface friction coupled with high surface hardness).
| Cutter Style | Square |
| Shank Diameter | 6.00mm |
| Flute Type | Helical |
| Shank Type | Weldon Flat |
| Overall Length | 63.00mm |
| Series | 07 |
| Milling Cutter Type | Slot Drill |
| Cutter Diameter Tolerance | e8 |
| Material | Cobalt High Speed Steel |
| Shank Diameter Tolerance | H6 |
| Material Grade | M42 |
| Number of Flutes | 3 |
| Length Type | Long |
| System of Measurement | Metric |
| Flute Length | 19.00mm |
| Standards Met | DIN 844 | DIN 1835B |
| Cutting Direction | Right Hand |
| Finish/Coating | Uncoated |
| Coolant Delivery | External |
| Plunge Type | Centre Cutting |
| End Mill Type | Slot Drill |
| Cutter Diameter | 4.00mm |
