Series 48 - 3 Flute - Short Series, TiCN Coated
Centre cutting.
Uncoated (for general production machining)
TiCN Coated (extends cutter life and improves work material surface finish)
TiALN Coated (dissipates and resists heat, reduces surface friction coupled with high surface hardness).
| Flute Type | Helical |
| Finish/Coating | TiCN |
| Standards Met | DIN 6535 HA |
| Shank Diameter | 10mm |
| Cutter Diameter Tolerance | H10 |
| Number of Flutes | 3 |
| Product Type | Slot Drills |
| Milling Cutter Type | Slot Drill |
| Overall Length | 60.0mm |
| Shank Diameter Tolerance | H6 |
| Series | Series 48 |
| System of Measurement | Metric |
| Coolant Delivery | External |
| Shank Type | Plain Round |
| Plunge Type | Centre Cutting |
| Flute Length | 22mm |
| End Mill Type | Slot Drill |
| Cutter Style | Square End |
| Material | Carbide |
| Cutting Direction | Right Hand |
| Length Type | Short |
| Cutter Diameter | 10mm |
