Series 48 - 3 Flute - Short Series
Dimensions to DIN 6535 HA. Centre cutting.
Uncoated (for general production machining)
TiCN Coated (extends cutter life and improves work material surface finish)
TiALN Coated (dissipates and resists heat, reduces surface friction coupled with high surface hardness).
| Shank Diameter Tolerance | H6 |
| Cutter Diameter | 3mm |
| System of Measurement | Metric |
| Flute Type | Helical |
| Standards Met | DIN 6535 HA |
| Series | Series 48 |
| Cutter Diameter Tolerance | H10 |
| Shank Type | Plain Round |
| Number of Flutes | 3 |
| Material | Carbide |
| Coolant Delivery | External |
| Cutter Style | Square End |
| Product Type | Slot Drills |
| Length Type | Short |
| Flute Length | 12mm |
| Plunge Type | Centre Cutting |
| Overall Length | 32.0mm |
| Cutting Direction | Right Hand |
| End Mill Type | Slot Drill |
| Shank Diameter | 3mm |
| Milling Cutter Type | Slot Drill |
| Finish/Coating | TiAlN |
