Spiral Point/Gun Nose - BSP - British Standard Pipe
Bright Finish. DIN 5156. For through holes. Taper lead to DIN form B. (3.5 x P to 5.5 x P). Tapping tolerance to 6H.
| Teeth per Inch | 28 |
| Class of Fit | 6H |
| Pitch | 28 |
| Square Width | 5.5mm |
| Material Application | Brass | Bronze | Mild Steel | Non-Alloy Carbon Steel |
| Ring Colour | Yellow |
| Material Grade | M35 |
| Shank Diameter | 7mm |
| Coolant Delivery | External |
| Overall Length | 90mm |
| Thread Size | 1/8\ |
| Dimensions Standard | DIN 371/376 |
| Product Type | Taps |
| Number of Flutes | 3 |
| Thread Length | 20mm |
| Thread Standard | BSP |
| Material | Vanadium High Speed Steel |
| Thread Direction | Right Hand |
| Finish/Coating | Steam Tempered |
| Tap Type | Spiral Point |
