Spiral Flute - BSP - British Standard Pipe Bright Finish
DIN 5156. For blind holes. Taper lead to DIN form C (3 x P). Tapping tolerance: Spiral flute to 6H.
| Thread Size | 3/8in |
| Helix Angle | 40 |
| Material Grade | M35 |
| Thread Standard | BSP |
| Tap Type | Spiral Flute |
| Shank Diameter | 12.0mm |
| Teeth per Inch | 19 |
| Dimensions Standard | DIN 5156 |
| Square Width | 9.0mm |
| Material Application | Brass | Bronze | Mild Steel | Non-Alloy Carbon Steel |
| Ring Colour | Yellow |
| Material | Vanadium High Speed Steel |
| Thread Direction | Right Hand |
| Pitch | 19.0 |
| Finish/Coating | Bright |
| Coolant Delivery | External |
| Class of Fit | 6H |
| Overall Length | 100mm |
| Number of Flutes | 3 |
| Thread Length | 22.00mm |
