Series T100 HSS taper shank drills are designed to drill steels with a tensile strength up to 1.000 N/mm2 as well as cast steel, grey cast iron, malleable cast iron, nickel brass and graphite.
Features and Benefits
HSS for excellent tool durability
Oxidised finish for excellent heat and wear resistance
Designed to drill steels with a tensile strength up to 1.000 N/mm2
Standards
Manufacturing Standard: DIN 345
| Finish/Coating | Black Oxide |
| Point Angle | 118\u00b0 |
| Drill Diameter Metric | 3.3 |
| Drill Length Type | Standard Length |
| Flute Type | Spiral |
| Standards Met | DIN 345 |
| Helix Angle | Normal |
| Shank Diameter Tolerance | DIN 228 |
| Product Type | HSS T/S Drill |
| Taper Shank Size | MT1 |
| Drill Diameter | 3.3mm |
| Material | HSS |
| Flute Length | 36mm |
| Series | T100 |
| Point Type | Thinned Point |
| Overall Length | 117mm |
| Coolant Delivery | External |
| Size | 3.3mm |
| Cutting Direction | Right Hand |
| Drill Diameter Tolerance | H8 |
