Series T100 HSS taper shank drills are designed to drill steels with a tensile strength up to 1.000 N/mm2 as well as cast steel, grey cast iron, malleable cast iron, nickel brass and graphite.
Features and Benefits
HSS for excellent tool durability
Oxidised finish for excellent heat and wear resistance
Designed to drill steels with a tensile strength up to 1.000 N/mm2
Standards
Manufacturing Standard: DIN 345
| Cutting Direction | Right Hand |
| Flute Length | 125mm |
| Product Type | HSS T/S Drill |
| Taper Shank Size | MT2 |
| Flute Type | Spiral |
| Size | 16.5mm |
| Finish/Coating | Black Oxide |
| Drill Diameter Tolerance | H8 |
| Drill Length Type | Standard Length |
| Drill Diameter | 16.5mm |
| Drill Diameter Metric | 16.5 |
| Overall Length | 223mm |
| Helix Angle | Normal |
| Coolant Delivery | External |
| Material | HSS |
| Standards Met | DIN 345 |
| Point Type | Thinned Point |
| Series | T100 |
| Shank Diameter Tolerance | DIN 228 |
| Point Angle | 118\u00b0 |
