Series T100 HSS taper shank drills are designed to drill steels with a tensile strength up to 1.000 N/mm2 as well as cast steel, grey cast iron, malleable cast iron, nickel brass and graphite.
Features and Benefits
HSS for excellent tool durability
Oxidised finish for excellent heat and wear resistance
Designed to drill steels with a tensile strength up to 1.000 N/mm2
Standards
Manufacturing Standard: DIN 345
| Finish/Coating | Black Oxide |
| Flute Type | Spiral |
| Shank Diameter Tolerance | DIN 228 |
| Flute Length | 175mm |
| Drill Diameter Tolerance | H8 |
| Taper Shank Size | MT3 |
| Standards Met | DIN 345 |
| Cutting Direction | Right Hand |
| Point Angle | 118\u00b0 |
| Drill Diameter | 30mm |
| Helix Angle | Normal |
| Drill Length Type | Standard Length |
| Material | HSS |
| Product Type | HSS T/S Drill |
| Drill Diameter Metric | 30 |
| Size | 30.0mm |
| Coolant Delivery | External |
| Series | T100 |
| Overall Length | 296mm |
| Point Type | Thinned Point |
