Series T100 HSS taper shank drills are designed to drill steels with a tensile strength up to 1.000 N/mm2 as well as cast steel, grey cast iron, malleable cast iron, nickel brass and graphite.
Features and Benefits
HSS for excellent tool durability
Oxidised finish for excellent heat and wear resistance
Designed to drill steels with a tensile strength up to 1.000 N/mm2
Standards
Manufacturing Standard: DIN 345
| Finish/Coating | Black Oxide |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Material | HSS |
| Overall Length | 248mm |
| Helix Angle | Normal |
| Coolant Delivery | External |
| Point Angle | 118\u00b0 |
| Drill Diameter | 21.75mm |
| Point Type | Thinned Point |
| Drill Diameter Metric | 21.75 |
| Drill Diameter Tolerance | H8 |
| Taper Shank Size | MT2 |
| Product Type | HSS T/S Drill |
| Shank Diameter Tolerance | DIN 228 |
| Size | 21.75mm |
| Standards Met | DIN 345 |
| Flute Length | 150mm |
| Series | T100 |
| Drill Length Type | Standard Length |
