Series T100 HSS taper shank drills are designed to drill steels with a tensile strength up to 1.000 N/mm2 as well as cast steel, grey cast iron, malleable cast iron, nickel brass and graphite.
Features and Benefits
HSS for excellent tool durability
Oxidised finish for excellent heat and wear resistance
Designed to drill steels with a tensile strength up to 1.000 N/mm2
Standards
Manufacturing Standard: DIN 345
| Size | 4mm |
| Series | T100 |
| Flute Length | 43mm |
| Shank Diameter Tolerance | DIN 228 |
| Standards Met | DIN 345 |
| Material | HSS |
| Overall Length | 123mm |
| Point Type | Thinned Point |
| Point Angle | 118\u00b0 |
| Flute Type | Spiral |
| Drill Diameter Metric | 4 |
| Drill Length Type | Standard Length |
| Coolant Delivery | External |
| Finish/Coating | Black Oxide |
| Product Type | HSS T/S Drill |
| Taper Shank Size | MT1 |
| Cutting Direction | Right Hand |
| Helix Angle | Normal |
| Drill Diameter Tolerance | H8 |
| Drill Diameter | 4mm |
