£9.90
HP Beyond Drills Steel Through CoolantHigh-Performance Solid Carbide Drills
Unit Measured | Metric |
MFR Part No. | 4112515 |
Assembly Length | 76.579mm |
Flute Length | 77mm | 77.0000mm |
Helix Angle | 27.546 |
Adapter Style | Straight-Cylindrical |
Adapter Type | Cylindrical |
Adapter / Shank / Bore Diameter | 14.0000mm |
Drill Diameter Tolerance | 0.007000 to 0.025000mm |
Helix Type | Right Hand Helix/Flute |
Flute Construction | Helical Flute |
Shank Length | 45.0000mm |
Hand Preference | Right |
Primary Material | Steel |
Functional Length | 121.5790mm |
Finish/Coating | TiAlN |
Number of Flutes | 2 |
Material | Carbide |
Drill Depth | 60mm | 60.0000mm |
Coolant Supplied | Yes |
Overall Length | 124mm | 124.0000mm |
Drill Point | 2.421mm |
Drill Diameter | 13.0000mm |
Clamping Length | 45mm |
