CCMT
Grade KC850
M25-M45, P25-P45. A tri-phase coating on an extra strong, cobalt-enriched substrate. For heavy cutting of low,medium, and high carbon steels, as well as medium hardness alloy and tool steels. Excellent thermal and mechanical shock resistance makes this grade ideally suited for difficult interrupted cuts.
| Insert Style | CCMT |
| Chipbreaker | LF |
| Clearance Angle | 7\u00b0 |
| Thickness | 3.97mm |
| Insert Size | 09T308 |
| MFR Part No. | 1162361 |
| ISO Designation | CCMT 09T308LF |
| Manufacturer Grade | KC850 |
| ISO Category | M | P |
| Shape | 80\u00b0 Rhombic |
| Corner Radius | 0.8 |
| Finish/Coating | TiC/TiCN/TiN |
| Material Application | Steels |
| Cutting Edge Length | 9.7mm |
| ISO Cut | M25 to M45 |
| Inscribed Circle | 9.525mm |
| ISO Category Grade | M |
| Pack Quantity | 1 |
| Material | Carbide |
| Cutting Direction | Neutral |
