HP Beyond Four-Margin, Long-Length Drills Through Coolant 12 x D
High-Performance Solid Carbide Drills
| Unit Measured | Metric |
| Primary Material | Steel |
| Material | Carbide |
| Hand Preference | Right |
| Coolant Supplied | Yes |
| Functional Length | 92.3200mm |
| MFR Part No. | 5131942 |
| Finish/Coating | TiAlN |
| Helix Type | Right Hand Helix/Flute |
| Number of Flutes | 2 |
| Overall Length | 93mm | 93.0000mm |
| Drill Diameter Tolerance | 0.004000 to 0.016000mm |
| Shank Length | 36.0000mm |
| Assembly Length | 56.32mm |
| Adapter Type | Cylindrical |
| Drill Point | 0.68mm |
| Drill Depth | 45mm | 45.0000mm |
| Helix Angle | 31.577 |
| Flute Construction | Helical Flute |
| Coolant Diameter | 0.5600mm (0.0882in) |
| Flute Length | 54mm | 54.0000mm |
| Drill Diameter | 3.6000mm |
| Adapter Style | Straight-Cylindrical |
| Adapter / Shank / Bore Diameter | 6.0000mm |
