Product Range: Coromant U
| Unit Measured | Metric |
| Insert Style | WCMX |
| Through Hole Function Property | Yes |
| Weight | 1.1g |
| Material | Carbide |
| Fixing Hole Diameter | 2.8mm |
| Insert Mounting Style | Screw/Clamp |
| Grade | 235 |
| CoroPak | 84.1 |
| Chipbreaker | 53 |
| MFR Part No. | 5756104 |
| Inscribed Circle Diameter | 5.71mm |
| Insert Usage Code | Peripheral |
| Manufacturer Grade | 235 |
| Series | 880 |
| Insert Shape | Trigon |
| Product Type | Insert for Drilling |
| ISO Designation | WCMX 03 02 08 R-53 235 |
| Insert Thickness | 2.38mm |
| Drilling System | CoroDrill 880 |
| Coating Process Type | CVD |
| Coating Type | TiCN+TiN |
| Insert Rake Angle | 18\u00b0 |
| Corner Radius | 0.8mm |
| Cutting Edge Count | 3 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Insert Size | 302 |
| Insert Size/Shape | CoroDrill U WC0302xx |
