This double-sided square TCMT turning insert has a positive insert geometry and was designed for the fine to medium machining of steels. The inscribed circle has a diameter of 6.35mm, 2.38mm thickness, and a 0.8mm nose radius.
Features and Benefits
Each insert is of the highest coated turning grade, bringing greater stability and performance in a variety of cutting conditions
Thicker coating significantly improves tool durability and increases productivity by allowing for higher cutting speeds
Processed post-treatment to improve the toughness and reliability of cutting-edge
Typical Applications
Cast steel
Steel
| ISO Category Grade | P |
| Material Application | Cast Iron | Cast Steel | Hardened Materials | Steels |
| Manufacturer Grade | T9415 |
| ISO Cut | P05 - P30 |
| Thickness | 3.97mm |
| Finish/Coating | MT-CVD |
| Insert Style | TCMT |
| MFR Part No. | 8244378 |
| Shape | 60\u00b0 Triangle |
| Clearance Angle | 7\u00b0 |
| ISO Designation | TCMT 16T312E-RM |
| ISO Category | P |
| Inscribed Circle | 9.53mm |
| Cutting Edge Length | 16.5mm |
| Chipbreaker | RM |
| Material | Carbide |
| Corner Radius | 1.2 |
