Size range: M3 - M20. Tapping tolerance: 6H.
| Thread Direction | Right Hnd |
| Applications | M - Stainless steel |
| Lead | Second |
| Class of Fit | 6H |
| Tap Chamfer Style | B 3.5 - 5 |
| Thread Size | M8 |
| Cutting Direction | Right |
| Finish | SUPER-B |
| Product Series | E241 |
| Product Type | Taps |
| Application | Stainless Steels |
| Shank | Cylindrical Shank with Square |
| Dimensions Standard | DIN 371 |
| Series | E241 |
| Thread Standard | Metric Coarse |
| Material | HSS-E-PM |
| Pitch | 1.25mm |
| Shank Diameter | 8mm |
| MFR Part No. | E241M8 |
| Material Grade | M35 |
| Thread Length | 18mm |
| Finish/Coating | Super B |
| Tapping Depth | 35mm |
| Overall Length | 90mm |
| Standards | DIN 371 |
| Square Width | 6.2mm |
| Tap Type | Spiral Point |
| Flute Geometry (FDC) | Spiral\u00a0Point Geometry |
| Number of Flutes | 3 |
| Unit of Measurement | Metric |
| Tap Application | Through Hole |
| Thread Form | M - Metric coarse |
