16ER 0.80 ISO Threading Insert Grade IC908

ER/L Metric External Threading Inserts ER/L - ground periphery and rake ERB - with a chipformer and peripherally ground ERM - with a chipformer Grade IC908 (P15-P30, M20-M30, K20-K30) PVD coated. Suitable for low to medium speed. IC908 high toughness for interrupted cuts. Excellent notch wear and build up edge resistance.

Insert Type	Laydown
ISO Designation	16ER 0.80 ISO
Finish/Coating	TiAlN
Thread Standard	ISO metric
Threading Location	External
Material	Carbide
Insert Size	16
ISO Category Grade	K | M | P
Cutting Direction	Right Hand
Thread Pitch	0.8
Thread Profile Type	Full Profile
Manufacturer Grade	IC908
Thread Height Difference	0.6mm
Insert Length	16mm
Material Application	Cast Iron | Stainless Steels | Steels
Number of Cutting Points	3
Side to Cutting Tip	0.6mm
Inscribed Circle	9.525in
ISO Cut	K20 to K40 | M20 to M30 | P15 to P30
