WNMG Turning Inserts
80 Trigon Insert
Insert Grade QX8010
(ISO M10 S10) Coated. Excellent grade giving superior results on heat resistant super alloys, especially for the aerospace industry. TiAln based coating ensures high wear resistance on these demanding materials.
Chip Breaker: NSA. Application: Light Cut.
Chip Breaker: NSS. Application: Light/Medium.
| Insert Size | 060408 |
| Finish/Coating | TiAlN |
| Thickness | 4.76mm |
| Chipbreaker | NSS |
| Cutting Edge Length | 6.5mm |
| ISO Category | M | S |
| Clearance Angle | 0\u00b0 |
| Cutting Direction | Neutral |
| MFR Part No. | 1-02-034737 |
| ISO Category Grade | M | S |
| ISO Cut | M10 | S10 |
| Insert Style | WNMG |
| Corner Radius | 0.8 |
| ISO Designation | WNMG 060408-NSS |
| Material Application | Alloy | Stainless Steels |
| Inscribed Circle | 9.525mm |
| Manufacturer Grade | QX8010 |
| Material | Carbide |
| Shape | Trigon |
| Pack Quantity | 1 |
