Series T100 HSS taper shank drills are designed to drill steels with a tensile strength up to 1.000 N/mm2 as well as cast steel, grey cast iron, malleable cast iron, nickel brass and graphite.
Features and Benefits
HSS for excellent tool durability
Oxidised finish for excellent heat and wear resistance
Designed to drill steels with a tensile strength up to 1.000 N/mm2
Standards
Manufacturing Standard: DIN 345
| Size | 20.75mm |
| Taper Shank Size | MT2 |
| Point Angle | 118\u00b0 |
| Drill Length Type | Standard Length |
| Finish/Coating | Black Oxide |
| Product Type | T/S Drill |
| Cutting Direction | Right Hand |
| Drill Diameter Metric | 20.75 |
| Overall Length | 243mm |
| Helix Angle | Normal |
| Standards Met | DIN 345 |
| Flute Type | Spiral |
| Series | T100 |
| Flute Length | 145mm |
| Material | HSS |
| Shank Diameter Tolerance | DIN 228 |
| Drill Diameter | 20.75mm |
| Drill Diameter Tolerance | H8 |
| Point Type | Thinned Point |
| Coolant Delivery | External |
