Series 48 - 3 Flute - Short Series, TiCN Coated
Centre cutting.
Uncoated (for general production machining)
TiCN Coated (extends cutter life and improves work material surface finish)
TiALN Coated (dissipates and resists heat, reduces surface friction coupled with high surface hardness).
| Cutter Diameter Tolerance | H10 |
| Standards Met | DIN 6535 HA |
| Length Type | Short |
| Flute Type | Helical |
| Shank Diameter Tolerance | H6 |
| Number of Flutes | 3 |
| Cutter Diameter | 1mm |
| Milling Cutter Type | Slot Drill |
| Product Type | Slot Drills |
| Shank Diameter | 4mm |
| Flute Length | 4mm |
| Cutter Style | Square End |
| Finish/Coating | TiCN |
| Series | Series 48 |
| Cutting Direction | Right Hand |
| System of Measurement | Metric |
| Plunge Type | Centre Cutting |
| Coolant Delivery | External |
| Shank Type | Plain Round |
| Material | Carbide |
| Overall Length | 40.5mm |
| End Mill Type | Slot Drill |
