BSPT HSS ground thread straight flute plug taps conforms to British Standard Pipe Taper specifications and are manufactured from HSS for increased strength when cutting.
Features and Benefits
HSS construction for greater strength
Precision ground flutes for improved tool accuracy
Heat and wear resistant properties for prolonged tool lifespan
Typical Applications
Tapping
Through holes
Blind holes
Standards
Tap dimensions conform to ISO529
| Teeth per Inch | 14 |
| Shank Diameter | 16.0mm |
| Thread Direction | Right Hand |
| Material | HSS |
| Overall Length | 87.0mm |
| Class of Fit | 6H |
| Finish/Coating | Bright |
| Number of Flutes | 4 |
| Material Grade | M2 |
| Tap Type | Straight Flute |
| Square Width | 12.50mm |
| Thread Size | 1/2in |
| Thread Length | 26.0mm |
| Chamfer | Plug |
| Dimensions Standard | ISO 529 |
| Pitch | 14 |
| Thread Standard | BSPT |
| Material Application | Aluminium | Cast Iron | Stainless Steels | Steels |
| ISO Category | K | M | N | P |
