GOdrill Wide Range of Materials
Solid Carbide Drills
| Primary Material | Steel |
| Material | Carbide |
| Flute Length | 53mm | 53.0000mm |
| Hand Preference | Right |
| Helix Type | Right Hand Helix/Flute |
| Drill Depth | 43mm | 43.0000mm |
| Adapter Style | Straight-Cylindrical |
| Clamping Length | 36mm |
| Coolant Supplied | No |
| Drill Diameter Tolerance | -0.015000 to 0.000000mm |
| Flute Construction | Helical Flute |
| Functional Length | 89.9400mm |
| Drill Diameter | 6.3000mm |
| Adapter Type | Cylindrical |
| Shank Length | 36.0000mm |
| Drill Point | 1.06mm |
| Adapter / Shank / Bore Diameter | 8.0000mm |
| Number of Flutes | 2 |
| Overall Length | 91mm | 91.0000mm |
| Helix Angle | 26.326 |
| Unit Measured | Metric |
| Assembly Length | 62.94mm |
| Finish/Coating | TiN |
| MFR Part No. | 4150686 |
