Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Usable Length | 80mm |
| Product Type | CoroMill Plura End Mill |
| Maximum Cutting Depth | 30mm |
| Coating Type | Uncoated |
| Corner Radius | 0.15mm |
| Grade | H10F |
| Rotational Speed Maximum | 10300 1/min |
| Unit Measured | Metric |
| Finish/Coating | Uncoated |
| CoroPak | 12.2 |
| MFR Part No. | 26260003 |
| Center Cutting Capability | Yes |
| Body Half Taper Angle | 30\u00b0 |
| Functional Length | 150mm |
| ISO Cutting Tool Material | Uncoated WC |
| Material | Solid Carbide |
| Maximum Ramping Angle | 15\u00b0 |
| Maximum Depth of Cut | 30mm |
| Basic Standard Group | Coromant |
| Coating Process Type | Uncoated |
| Connection Diameter | 20mm |
| Standards Met | COROMANT |
| Weight | 0.6kg |
| Cutting Diameter | 20mm |
| Coolant Entry Style | Without Coolant |
| Through Hole Function Property | Yes |
