Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Finish/Coating | Uncoated |
| Cutting Diameter | 7mm |
| Standards Met | COROMANT |
| Center Cutting Capability | Yes |
| Through Hole Function Property | Yes |
| Maximum Cutting Depth | 18mm |
| Usable Length | 18mm |
| Functional Length | 60mm |
| Product Type | CoroMill Plura End Mill |
| MFR Part No. | 26260088 |
| Maximum Depth of Cut | 18mm |
| Coolant Entry Style | Without Coolant |
| Material | Solid Carbide |
| ISO Cutting Tool Material | Uncoated WC |
| Coating Type | Uncoated |
| Rotational Speed Maximum | 80000 1/min |
| Coating Process Type | Uncoated |
| Connection Diameter | 69.85mm |
| Unit Measured | Metric |
| Basic Standard Group | Coromant |
| Grade | H10F |
| Corner Radius | 0.15mm |
| Maximum Ramping Angle | 15\u00b0 |
| CoroPak | 12.2 |
