Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Through Hole Function Property | Yes |
| Maximum Cutting Depth | 36mm |
| Standards Met | COROMANT |
| Coating Type | Uncoated |
| ISO Cutting Tool Material | Uncoated WC |
| Center Cutting Capability | Yes |
| Corner Radius | 0.15mm |
| Maximum Depth of Cut | 36mm |
| Usable Length | 36mm |
| Connection Diameter | 20mm |
| Unit Measured | Metric |
| Material | Solid Carbide |
| Functional Length | 104mm |
| MFR Part No. | 26260083 |
| Grade | H10F |
| Coating Process Type | Uncoated |
| Basic Standard Group | Coromant |
| Cutting Diameter | 20mm |
| Maximum Ramping Angle | 15\u00b0 |
| Coolant Entry Style | Without Coolant |
| Product Type | CoroMill Plura End Mill |
| Finish/Coating | Uncoated |
| CoroPak | 12.2 |
| Rotational Speed Maximum | 17900 1/min |
| Weight | 397.4g |
