Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Corner Radius | 0.5mm |
| MFR Part No. | 7858138 |
| Through Hole Function Property | Yes |
| Material | Solid Carbide |
| CoroPak | 20.2 |
| Connection Diameter | 6mm |
| Coating Process Type | PVD |
| Rotational Speed Maximum | 80000 1/min |
| Center Cutting Capability | Yes |
| Maximum Depth of Cut | 13mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Ramping Angle | 5\u00b0 |
| Standards Met | DIN 6527 L |
| Coating Type | TiAlN |
| Unit Measured | Metric |
| Maximum Cutting Depth | 13mm |
| Basic Standard Group | DIN 6527 L |
| Grade | 1725 |
| Shank Type | Weldon |
| Cutting Diameter | 5mm |
| Coolant Entry Style | Without Coolant |
| Product Type | Solid Carbide Endmill |
| Functional Length | 57mm |
| Usable Length | 16mm |
