Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Unit Measured | Metric |
| Cutting Diameter | 6mm |
| Coolant Entry Style | Without Coolant |
| MFR Part No. | 7858265 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Connection Diameter | 65.05mm |
| Standards Met | DIN 6527 L |
| Product Type | Solid Carbide Endmill |
| Material | Solid Carbide |
| Rotational Speed Maximum | 80000 1/min |
| Basic Standard Group | DIN 6527 L |
| Through Hole Function Property | Yes |
| Usable Length | 19mm |
| Coating Process Type | PVD |
| CoroPak | 20.2 |
| Maximum Cutting Depth | 13mm |
| Maximum Depth of Cut | 13mm |
| Maximum Ramping Angle | 5\u00b0 |
| Functional Length | 57mm |
| Center Cutting Capability | Yes |
| Grade | 1725 |
| Coating Type | TiAlN |
| Shank Type | Weldon |
