Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Through Hole Function Property | Yes |
| MFR Part No. | 7858270 |
| Usable Length | 52mm |
| Coating Process Type | PVD |
| Maximum Depth of Cut | 38mm |
| Grade | 1725 |
| Shank Type | Weldon |
| Maximum Cutting Depth | 38mm |
| Material | Solid Carbide |
| Standards Met | DIN 6527 L |
| Cutting Diameter | 20mm |
| Weight | 0.39kg |
| Coolant Entry Style | Without Coolant |
| Connection Diameter | 20mm |
| CoroPak | 20.2 |
| Maximum Ramping Angle | 5\u00b0 |
| Unit Measured | Metric |
| Functional Length | 104mm |
| Coating Type | TiAlN |
| Basic Standard Group | DIN 6527 L |
| Rotational Speed Maximum | 40000 1/min |
| Center Cutting Capability | Yes |
| Product Type | Solid Carbide Endmill |
| ISO Cutting Tool Material | Coated WC or Cermet |
